Outdoor Mesh led Display
Outdoor Mesh led Display
★ Higher stability for building facade displaying
★ No air cooler and fan, but better heat-dissipation
★ Higher transparency rate
★ Low cost
★ Light weight
★ Front access. Easy maintenance with less tool required
★ Higher brightness, lower power consumption
| Mesh LED Display | ||||
| Pixel Pitch(mm) | 8-16 | 16-16 | 16-16 | 16-33 |
| LED Lamp Type | SMD3535 | SMD3535 | DIP346 | DIP346 |
| LED Configuration | SMD 3IN1 | SMD 3IN1 | 1R1G1B | 1R1G1B |
| Module Size(H*W*T) | 1000*9.5*11 | 1000*9.5*11 | 1000*10*18 | 1000*10*18 |
| Cabinet Size(H"W*T) | 1000*500*60 | 1000*500*60 | 1000*500*60 | 1000*500*60 |
| Viewing Angle(H/V) | 120/120 | 120/120 | 120/60 | 120/60 |
| Brightness(Cds/m2) | >6000 | >6000 | >6500 | 6500 |
| Transparency | 38% | 38% | 38% | 70% |
| Reflash Rate(Hz) | 1920-3840 | 1920-3840 | 1920-3840 | 1920-3840 |
| Gray Scale(Bit) | 14 | 14 | 14 | 14 |
| Power Consumption(Max/Avg W/m2) | 450/150 | 450/150 | 450/150 | 450/150 |
| Ip Rate(Front/Rear) | 65/65 | 65/65 | 65/65 | 65/65 |
| Working Voltage(V) | 110/220 | 110/220 | 110/220 | 110/220 |
| Working Temperature | -20-65°C | -20-65°C | -20-65°C | -20-65°C |
| Working Humidity | 10%-95% | 10%-95% | 10%-95% | 10%-95% |
